Kriega US Hook Strap Set, US-10 and 20, up to 90-liter

FEATURES
Upgrade alloy hook straps for older-generation US-10 and 20 packs (standard for post-2012 products). The highly secure subframe mounting kit allows combination with tail bags of up to 90 litres. The mounting straps are designed to fit virtually any type of motorcycle. Particularly suitable for traditional one-piece seats or bolt-on seat pads/frames.
Fitting
NB - Some motorcycles already have webbing loops attached to the seat pad/base. In this case, we still recommend fitting the Kriega loops, as attachment to the subframe is much stronger than attachment to the seat. Remove the motorcycle seat and locate the best attachment points on the rear subframe. If the metal section of the subframe is not visible, slotting the inner plastic base may be necessary. Securely attach the 4x 20 mm webbing loops to strong areas of the frame. The 20 mm loops are adjustable in length. Final adjustments should be made with the seat/pad fitted. If the webbing has sagged, it must be threaded back through the adjuster to lock the strap. See the threading diagram on this page. To fit the US pack, attach the webbing loop, fasten the upper quick-release buckle and secure the bag to the motorcycle. Always use the 2 x strap keepers on the webbing to manage loose ends. Also ensure that the quick-release buckles are correctly clicked into place
TECHNICAL DATA
Custom 6061-T6 alloy hooks
Multi-position seat: inside or across the motorcycle seat
Easy to switch on/off the motorcycle
No loose straps left on the motorcycle
Std. strap length 600mm
4 x Acetal ITW Airloc buckles
4 x 20 mm subframe loops
10-year warranty
WEIGHT
200,00 grams
