Fuel hose elbow 55° inclined -BGM PRO- Vespa (Ø outer = 10.0mm, Ø inner = 7.0mm) - stainless steel

petrol hose elbow from BGM made of stainless steel. First offered under the sales name `Ron Bogen` in the German Scooter Forum. This is placed directly after the fuel tap in the hose and offers a much better connection possibility for the fuel hose due to a 55° deflection.
This effectively prevents the hose from kinking, the engine always receives a full charge of fresh fuel.

The installation is carried out as close as possible to the outlet of the fuel tap. To do this, attach a short piece of fuel hose (approx. 3-4cm) to the fuel tap, then the fuel hose elbow and the remaining hose to the carburettor.

• Fits the standard Piaggio fuel hose with Ø7mm inner diameter

• Supplied with hose clips

TIP: Basic rule for routing the hose: as short as possible as long as necessary. Always attach the hose to the tank/bow first, insert the tank and only then connect it to the carburettor. This is the only way to achieve the shortest possible hose length.

A good alternative to the original fuel hose is the spiral wire reinforced Toyox hose (see accessories). This is an ideal supplement due to the incorporated reinforcement. For easier assembly, heat the ends.
