injection module Malossi Force Master 2.1 for Vespa GTS/GTS Super/GTS Super

The Force Master 2.1 ECU has a completely new look and is much easier to configure. With an interface for the K and CAN communication lines, a new user interface and the addition of a capacitive ignition input, the Force Master 2.1 is the ideal complement for the vehicle's power management: without functional limitations, it allows the engine to rev beyond the limit of the original rev limiter.

Technical data

• Carburetor setting
• Injection rate: ± 14% LOW / HIGH / MEDIUM
• Speed limiter: +1,000 rpm
• Temperature range: -30°C +80°C
• Minimum operating voltage: +7V
• Maximum operating voltage: +16V
• Average current consumption: <-200mA
• Safety class: IP65

4 different mappings:

• Curve 0: Malossi with DB killer exhaust system, original cylinder, original head, original camshaft, original filter
• Curve 1: Malossi with DB killer exhaust system, original cylinder, Malossi head, original camshaft, original filter
• Curve 2: Original exhaust system, Malossi cylinder, Malossi head, original camshaft, original filter
• Curve 3: Malossi with DB killer exhaust system, Malossi cylinder, Malossi head, original camshaft, original filter
